Prepuller Action: GitOps-native Image Caching, as Code

Most Kubernetes clusters quietly rely on image pulls working. Kubelet caches whatever it has pulled, so a pod that’s already running on a node stays running even if the registry is unreachable. The failure surface is the edges: a pod rescheduled to a node that has never seen the image, a new node joining the cluster, a rollout referencing a tag that hasn’t been replicated to the mirror yet, or Docker Hub rate limits (anonymous pulls are capped at 100 per 6 hours per IP) kicking in right when a rolling update needs them. Any of those combined with a slow, flaky, or unreachable registry gets you ImagePullBackOff.

The usual answer is a pre-puller DaemonSet: a pod on every node whose job is to pull a set of images into the local cache and keep them there. Writing one by hand is fine. Keeping a dozen of them aligned with whatever versions your HelmReleases actually use is the chore. That’s what this tool automates.

What it does

The prepuller is a Forgejo Action (works the same as a GitHub Action) that reads your GitOps repo, finds every HelmRelease you’ve marked for pre-pulling, renders each chart offline, extracts the container images the chart would deploy, and writes a DaemonSet manifest into the repo. Flux picks the manifests up on the next reconcile and rolls them out. From then on, those images sit in the local image cache on every worker node. The generated DaemonSet has no tolerations by default, so control-plane nodes are excluded (which is usually what you want; extend the action to add tolerations if you run workloads on control-plane nodes too).

The opt-in is a single label on the HelmRelease:

apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
  name: my-workload
  namespace: platform
  labels:
    example.com/prepuller: "enabled"
spec:
  chartRef:
    kind: OCIRepository
    name: my-workload
    namespace: flux-system
  values: {}

No per-workload boilerplate. No repeating the image list in a second manifest. No drift between what the chart renders and what the cache holds.

How it works

End-to-end, from a helmrelease.yaml change to an image sitting in the local kubelet cache:

    flowchart LR
    A[Push to main] --> B{Changed files<br/>relevant?}
    B -- No --> Z[Exit]
    B -- Yes --> C[Discover HelmRepository<br/>+ OCIRepository sources]
    C --> D[Find labeled<br/>HelmReleases]
    D --> E[helm pull + template<br/>with values]
    E --> F[Extract images<br/>per release]
    F --> G[Write DaemonSet<br/>manifests + kustomization]
    G --> H[Commit back to main]
    H --> I[Flux reconcile<br/>deploys DaemonSets]
    I --> J[Kubelet caches images<br/>on every worker node]


Step by step:

1. Discover chart sources. Walk the repo for every HelmRepository and OCIRepository resource. Build a lookup map keyed by namespace/name.
2. Discover labeled HelmReleases. Pre-filter YAML files with grep (far faster than running yq across the whole repo), then validate each hit with yq to confirm it really is a HelmRelease with the label set to enabled.
3. Parse each HelmRelease. Support both source patterns: spec.chart.spec.{chart,version,sourceRef} (HelmRepository-backed) and spec.chartRef (OCIRepository-backed). For chartRef, derive the chart name from the URL basename and the version from spec.ref.tag or spec.ref.semver.
4. Pull and template each chart. helm pull for the chart, helm template with the HelmRelease’s own values. Pass --api-versions for common CRDs so charts gating on .Capabilities.APIVersions.Has (for example, ServiceMonitor checks in monitoring stacks) don’t fail when rendered offline.
5. Extract images. Grep the rendered manifest for image: lines, apply an exclusion regex for containers you never want to cache (analyzers, exporters, CI runners), and normalize any mangled paths where a chart concatenated its default registry with a user override.
6. Emit a DaemonSet. For each workload, write infrastructure/prepullers/prepuller-<release>.yaml: one tiny initContainer per image plus a single pause container to keep the pod alive. The initContainers reference the images and exit immediately. Kubelet pulls each image once while scheduling them.
7. Regenerate the kustomization. Rewrite infrastructure/prepullers/kustomization.yaml to list exactly the prepullers that should be active, so deletions propagate cleanly.
8. Commit. If anything changed, push a chore: update prepuller images commit back to main. Flux deploys the new DaemonSets on the next reconcile.

The workflow triggers on pushes to main that touch infrastructure/controllers/**/helmrelease*.yaml or infrastructure/sources/**, plus a manual dispatch for full regeneration. A pre-check job uses git diff to skip the heavy work when nothing relevant changed.

The DaemonSet itself is small by design. A simplified view:

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: prepuller-my-workload
  namespace: platform
spec:
  selector: { matchLabels: { name: prepuller-my-workload } }
  template:
    metadata:
      labels: { name: prepuller-my-workload }
    spec:
      initContainers:
        - name: prepull-my-image-0
          image: my-registry.example.com/repl-my-workload/my-image:v1.2.3
          command: ["/bin/true"]
          imagePullPolicy: IfNotPresent
      containers:
        - name: pause
          image: my-registry.example.com/pause:3.10
          imagePullPolicy: IfNotPresent
          resources:
            limits: { memory: 128Mi, cpu: "1" }
            requests: { memory: 5Mi, cpu: 5m }

Three details make this work in practice:

• imagePullPolicy: IfNotPresent on both init and pause containers, so kubelet reuses the local cache once it’s warm.
• The pause container stays running forever. Kubelet’s image garbage collector evicts images “in order based on the last time they were used” once disk usage crosses imageGCHighThresholdPercent (default 85%). The Kubernetes docs don’t formally spell out how completed-init-container images are treated, but empirically the pull-once-then-sit-in-pause pattern keeps the cached layers around on every node I’ve tested it on. If your nodes run hot on disk, tune imageGCHighThresholdPercent and imageMaximumGCAge rather than expecting the prepuller to win that fight unaided.
• Resource requests are minimal so the pod schedules on nodes that are otherwise fully packed.

Why it’s beneficial

A few concrete wins that show up the moment this is in place:

• Faster pod startup on reschedules. When a pod moves to a new node, its image is already in the local cache. Startup goes from “pull a multi-hundred-megabyte image, then start” to “start.” For critical services this is the difference between a blip and a visible outage during node maintenance.
• Insulation from registry outages. An unreachable registry stops hurting scheduling decisions on nodes that already have the image. In clusters where the registry is self-hosted, this breaks circular bootstrap dependencies: the components needed to bring the registry back up are already cached and don’t need to be fetched from the thing that’s down.
• Partial protection against registry retention. Mirrored registries often run aggressive retention (keep the last N tags, evict anything older). With imagePullPolicy: IfNotPresent, the running DaemonSet itself doesn’t re-pull once it’s warm, so the registry only sees a pull when (a) a new node joins and the DaemonSet schedules there, (b) a pod restarts (rollout, eviction, reboot), or (c) the DaemonSet is re-rendered with a new image tag. On autoscaled fleets and short-lived-node environments that’s enough steady signal to keep tags alive. On stable bare-metal, it isn’t, so pair it with explicit retention rules for tags you care about.
• Insulation from Docker Hub rate limits. Each node pulls each image exactly once; subsequent pod starts use the local cache. Combined with a pull-through mirror (Harbor, Artifactory, Nexus), the mirror absorbs the first pull and the prepuller keeps the nodes warm so nothing repeatedly hits Docker Hub.
• Declarative and visible. The full list of prepulled images for every workload lives as rendered YAML in the repo. Code review catches regressions (“why did this image suddenly get added to the cache?”) before they hit the cluster. Diffing two commits tells you exactly which images changed.
• Zero ongoing maintenance per workload. Bumping a chart version changes the generated prepuller automatically at the next run. There’s nothing to update by hand.

Configuration

The action step, with the inputs that actually matter:

- uses: https://my-git.example.com/actions/prepuller@v2.4.2
  with:
    flux-monorepo: "true"
    cluster-name: my-cluster
    prepuller-output-path: infrastructure/prepullers
    prepuller-label: example.com/prepuller
    commit-changes: "true"

Wire it into a workflow that triggers on pushes to infrastructure/controllers/**/helmrelease*.yaml and infrastructure/sources/**, with workflow_dispatch for manual full regeneration. The generator runs entirely offline; cluster-name just points at a cluster-config.yaml for Flux postBuild substitution.

What it doesn’t solve

Two limits worth naming up front:

• A brand-new node during a registry outage still has nothing. The prepuller DaemonSet pod on that node can’t pull either. Once the registry comes back, the cache fills. This is a real edge, but it’s the same edge you’d have without any caching: provisioning nodes during an outage is a separate operational problem.
• Chart-default tag drift vs. registry retention. The prepuller caches whatever tag the chart currently uses. If a chart defaults a tag to something your registry doesn’t have replicated, the cache is empty and pulls still fail. The structural fix is pinning the tag in HelmRelease values rather than trusting chart defaults.

Alternatives

A few existing projects solve parts of the same problem. I looked at each before writing this one:

• kube-fledged is the classic DaemonSet-based pre-puller, but it’s unmaintained.
• kube-image-keeper (kuik) from enix is well maintained and actively developed. It’s a different shape of solution: a mutating webhook that rewrites pod image references to point at another registry (e.g., Harbor as a pull-through cache), plus optional replication between registries. It’s routing and redundancy for image pulls, not local-node pre-warming. It doesn’t put images into the kubelet cache on every node ahead of time, which is what I specifically wanted for bootstrap-critical components.
• che-incubator/kubernetes-image-puller is DaemonSet-based with the same broad shape as this tool. The difference is it takes a hand-curated image list via an IMAGES environment variable. Every time a chart version bumps, you’re responsible for updating the image list yourself. That’s the exact toil I wanted to eliminate.
• Cdayz/k8s-image-pre-puller is an operator with a PrePullImage CRD that generates a DaemonSet per resource. Similar problem to the above (the image list is declarative input, not derived from your workloads), and with a small user base (single-digit stars) I’d be on my own for any fixes.

My tool fills a narrow niche: you already run Flux, you already use HelmReleases, and you want “cache everything this HelmRelease’s chart says it wants” automatically, without maintaining a parallel image list. If you want a pull-through/routing layer instead, kuik is the well-maintained choice. If you’re happy maintaining the image list by hand, the two DaemonSet-based options above are simpler than running a generator.

“Can I See The Code?”

The action isn’t open-sourced. It’s tied closely enough to my GitOps layout and conventions (Flux monorepo, OCIRepository-heavy, specific label scheme) that a generic release would need more README than code to explain what doesn’t apply to you. If you’re curious about the implementation or want to compare notes, feel free to ping me on LinkedIn. Happy to share and chat about it.
